Heavy-Duty High Performance Winches

InterOcean range of heavy-duty oceanographic winches brings decades of design experience and proven performance to work for deep-tow, oceanographic, and geotechnical applications. These winches are engineered for handling long cables and high tension with multiple configuration options available for a customized solution.

Series 9933

Heavy-Duty Deepwater Oceanography WinchModel 9933 Deep Water Winch

A capable, heavy-duty oceanographic winch for deep tow and sampling applications. The Model 9933 is designed for handling long multi-conductor or coax cable, fiber-optic cable, or wire rope for open-ocean oceanographic work.

The Model 9933 is available with an all-electric drive, hydraulic, or electro-hydraulic configuration in a range from 50 hp to 150 hp. Hydraulic configurations offer direct connection to ship hydraulics, or it may be supplied with an integrated or independent HPU. Includes grooved drum and level wind systems to assure perfect repetitive spooling and maximum protection of long cables under demanding conditions. Cable monitoring, display, control options, auto-rendering, and motion-compensation are available.

Model 9602

Heavy-Duty Deepwater Oceanography Winch

The Model 9602 is another capable, heavy-duty winch for deep ocean towing and sampling applications, and is available with an electric, hydraulic, or electro-hydraulic drive system from 50 hp to 200 hp. Designed for high tension spooling and maximum protection of long cables under demanding conditions. Includes grooved drum and level wind system; cable monitoring, display,  control options, auto-rendering, and motion-compensation are available.

Model 75030 Heavy Duty WinchModel 75030

Heavy-Duty Deepwater Oceanography Winch

The Model 75030 is a multi-mission deepwater oceanographic winch with advanced spooling, level-winding, cable monitoring, safety, and control features. It also has the capacity for handling full ocean depth electrical or fiber-optic data cable or wire rope with appropriate working loads for multi-purpose oceanographic applications.

InterOcean Winches Brochure
